Description
The Clipper Prelude utilizes a 54” wide screen and provides adaptable screen arrangements. The 526 has three screen decks with a total of five (5) 54”Wx26”L screens. The top deck has one 26” long screen for scalping. The next two decks have two 26” long screens that can be set up for a scalp/sift or split sift screen configuration. With over 50 square feet screening capacity, precision separations can be made efficiently
Screens
The Prelude 526 has been designed with five sections 54″x26″. Over 175 different sizes of perforated metal or wire cloth screen are available. A complete set of five (5) screens, your choice of perforation, is provided.
Portability and operational stability distinguish the 526 from other sized cleaners. The 3”x3” tubular steel frame and smooth eccentric motion allow for many portable and permanent applications. The optional air system is designed to take full advantage of quick and efficient airlift separation. Fan velocity adjustments are easily made and will accommodate a wide range of commodities in various conditions.
The 526 is available as a base model without a fan/air system. Other models are available with an AC controllable Vibratory Hopper and/or controllable Shoe Shake. Hopper agitator kits and centralized grease line packages are also available.
Options
Please contact us for a custom quotation (800)692-5962
- Electronic Variable Speed Hopper
- Electronic Variable Speed Shoe Shake
- Grease Line Package
Capacities:
- Small seed 100 Bu/Hr
- Medium seed 175 Bu/Hr
- Large seed & wheat 300 Bu/Hr
- Market cleaning 600 Bu/Hr
- Dimensions: 90”Lx80″Wx91″H
- Shipping Dimensions: 96”Lx95”Wx92”H/48”Lx55”Wx35”H
